    Honeywell Linear Industrial Scanner Hyperion 1300g

    Honeywell Linear Industrial Scanner Hyperion 1300g
    Honeywell Linear Industrial Scanner Hyperion 1300g
    Send Inquiry
    Product Code : Hyperion 1300g
    Brand Name : Honeywell
    Product Description

    HONEYWELL Hyperion 1300g Linear Imaging Scanner is ideal for scan-intensive and light industrial applications.

    SPECIFICATION:

    • Dimensions: 150 mm x 112 mm x 79 mm (5.9x 4.4 x 3.1)
    • Weight: 160 g (5.6 oz)
    • Input Voltage: 5V ± 5%
    • Operating Power: 1000mW; 200 mA (typical) @ 5V
    • Operating Temperature: 0°C - 50°C (32°F to 122°F)
    • Humidity: 0 to 95% non-condensing
    • Scan Pattern: Single line

    FEATURES:

    • Superior Hand-Held Scanning
    • Highly Versatile
    • Class-Leading Durability
    • Comfortable, Ergonomic Design
    • Automatic Interface Detection
    • Remote Scanner Management Software
    Mechanical/Electrical
    •  Standby Power :625mw; 125 mA (typical) @ 5V
    • Host System Interfaces :Multi-Interface/includes RS232 (TTL +5V, 4 Signals)/KBW/USB (HID keyboard, serial, IBM OEM); RS-232C (±12V) and IBM RS485 supported via adapter cable
    •  Auxiliary Ports:N/A
    Environmental

     Storage Temperature: -40°C - 60°C (-40°F to 140°F)
     Drop/Tumble :Designed to withstand 50 drops on concrete from 1.5m
     Environmental Sealing : IP41
     Light Levels :0-70,000 lux (direct sunlight)

    Scan Performance
    •  Motion Tolerance:20 in (51cm) per second
    •  Scan Rate: Up to 270 scans per second
    •  Print Contrast  : 20% minimum reflectance difference
    •  Pitch, Skew: 65°, 65°
    •  Warranty:5 year factory warranty
