    Honeywell RFID Embedded Reader

    Honeywell RFID Embedded Reader
    Honeywell RFID Embedded Reader
    Product Code : IM11
    Brand Name : Honeywell
    Product Description

    HONEYWELL IM11 Ultra High Frequency RFID Reader Module is designed to serve market applications that require high performance at a low cost. It is one of the smallest and most cost-effective high-performance UHF reader modules available today – ideal for mobile computers and tablets, fixed position readers, handheld scanners and diagnostic equipment.

    FEATURES:

    • Easy to Integrate
    • Extremely Small
    • Cost Effective
    • Powerful
    • Efficient
    • Developer’s Kit Available

    SPECIFICATION:

    • Length: 50.95 mm (2.0 in)
    • Width: 30 mm (1.2 in)
    • Thickness: 4.76 mm (0.19 in)
    • Operating Temperature: -20°C to 60°C (-4°F to 140°F)
    • Humidity: 25 °C to 60 °C, 0% to 95% relative humidity, noncondensing
    • Operating Voltage: 2.8 to 5.2 VDC
    • Read Current: 1.3 Amps, typical (3.8V) @ 30 dB
    • Frequency Range: 860-928 MHz, regional dependent
    • Bus Interface: USB 2.0 compliant client 12 Mbps (full speed) Serial 115.2 Kbps
    • I/O Interface: 4 in/4 out
