    Scanners Granit 1980i

    Scanners Granit 1980i
    Scanners Granit 1980i
    Send Inquiry
    Product Code : Granit 1980i
    Brand Name : Honeywell
    Product Description

    HONEYWELL Granit 1980i industrial-grade scanner features full-range area-imaging technology capable of reading both 1D and 2D barcodes across a wide range of distances from 15 cm (6 in) to 15 m (50 ft).Granit 1980i scanners is IP65 rated to withstand harsh environments.

    FEATURES:
    • Full Range Area Imaging Performance
    • Efficient Wireless Performance
    • Single Scanning Solution
    • Built Granit Tough
    • Easy To Use

    SPECIFICATION:

    • Dimensions (LxWxH): 133 mm x 75 mm x 195 mm (5.2” x 2.9” x 7.6”)
    • Weight: 335 g (11.8 oz)
    • Input Voltage: 4.0 to 5.5 VDC
    • Operating Power: 2.35 W (470 mA @ 5.0 V)
    • Operating Temperature: -30°C to 50°C (-22°F to 122°F)
    • Humidity: 0 to 95% relative humidity, non-condensing
    • Light Levels: 0 to 100,000 lux (9,290 foot-candles)
    • Scan Pattern: Area Imager

    Electrical
    •  Standby Power :0.5 W (100 mA @ 5.0 V)
    •  Host System Interfaces : USB and True RS232
    Environmental
    •  Storage Temperature :-40°C to 70°C (-40°F to 158°F)
    •  Drop  :Designed to withstand 50 2m (6.5’) drops to concrete at -30°C
    •  Tumble :5,000 1m (40˝) tumbles
    •  Environmental Sealing : IP65
    •  Light Levels : 0 to 100,000 lux (9,290 foot-candles)
    •  ESD  : ±20Kv air discharge, ±8kV contact discharge
    Scan Performance
     Scan Angle   :Horizontal: 12.9°
     Symbol Contrast : 1D Codes: 30% minimum reflectance difference 2D Codes: 40% minimum reflectance difference
     Min. Resolution : 1D & 2D Codes: 2 mil
     Pitch, Skew:  70°, 80°
     Warranty  : 3 year factory warranty
