              Scanners Granit 1980i

              Scanners Granit 1980i
              Scanners Granit 1980i
              Send Inquiry
              Product Code : Granit 1980i
              Brand Name : Honeywell
              Product Description

              HONEYWELL Granit 1980i industrial-grade scanner features full-range area-imaging technology capable of reading both 1D and 2D barcodes across a wide range of distances from 15 cm (6 in) to 15 m (50 ft).Granit 1980i scanners is IP65 rated to withstand harsh environments.

              FEATURES:
              • Full Range Area Imaging Performance
              • Efficient Wireless Performance
              • Single Scanning Solution
              • Built Granit Tough
              • Easy To Use

              SPECIFICATION:

              • Dimensions (LxWxH): 133 mm x 75 mm x 195 mm (5.2” x 2.9” x 7.6”)
              • Weight: 335 g (11.8 oz)
              • Input Voltage: 4.0 to 5.5 VDC
              • Operating Power: 2.35 W (470 mA @ 5.0 V)
              • Operating Temperature: -30°C to 50°C (-22°F to 122°F)
              • Humidity: 0 to 95% relative humidity, non-condensing
              • Light Levels: 0 to 100,000 lux (9,290 foot-candles)
              • Scan Pattern: Area Imager

              Electrical
              •  Standby Power :0.5 W (100 mA @ 5.0 V)
              •  Host System Interfaces : USB and True RS232
              Environmental
              •  Storage Temperature :-40°C to 70°C (-40°F to 158°F)
              •  Drop  :Designed to withstand 50 2m (6.5’) drops to concrete at -30°C
              •  Tumble :5,000 1m (40˝) tumbles
              •  Environmental Sealing : IP65
              •  Light Levels : 0 to 100,000 lux (9,290 foot-candles)
              •  ESD  : ±20Kv air discharge, ±8kV contact discharge
              Scan Performance
              •  Scan Angle   :Horizontal: 12.9°
              •  Symbol Contrast : 1D Codes: 30% minimum reflectance difference 2D Codes: 40% minimum reflectance difference
              •  Min. Resolution : 1D & 2D Codes: 2 mil
              •  Pitch, Skew:  70°, 80°
              •  Warranty  : 3 year factory warranty
