Honeywell Limit Switch HLS-F

Name: Honeywell Limit Switch HLS-F
Brand: FUTURISTIC TECHNOLOGIES
Price: 1250 INR
Availability: InStock

Price 1250 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Honeywell Limit Switch HLS-F Specification

Circuit Type
SPDT

Max. Current
10A max.

Automation Grade
Automatic

Rated Voltage
250V AC

Finish Type
Matte

Temperature Range
-20C to +70C

Response Time
10 ms

Mechanical Life
10,000,000 operations

Number of Module
Single

Protection Level
IP65

Product Type
Limit Switch

Material
Metal Body, Plastic Head

Insulation Resistance
100 M min (at 500VDC)

Contact Resistance
25 m max.

Max. Voltage
250-500 Volt (V)

Operating Temperature
-20C to 70C

Stoke
10 mm

Size
Standard

Color
Blue

Weight
Approx. 300g

Mounting Type
Panel Mount

Current Rating
10A at 250V AC

No Of Poles
1 Pole

Switch Type
Momentary

Wire Entry
M20 x 1.5 mm

Applications
Industrial Automation, Machine Tools, Conveyor Systems

Contact Type
Silver alloy

Ingress Protection
IP65

Electrical Life
500,000 operations (at rated load)

Standards Compliance
IEC, CE Certified

Actuator Type
Roller Plunger

Honeywell Limit Switch HLS-F Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Days

Main Domestic Market
All India

About Honeywell Limit Switch HLS-F

Honeywell HLS-F Limit Switch

Honeywell HLS-F Limit Switch Features:-

Standard Mounting dimension, suitable for small mounting space

10A current capacity

Highly rigid construction (head and cover snugly fit in box)

Pre-molded flexible cable gland for fast and simple wiring termination

Wide range of actuators available

CCC, CE approved

IP65 Rated

Precision and Reliability for Industrial Tasks

Engineered for industrial automation, the Honeywell HLS-F Limit Switch offers exceptional repeatability and reliability for machine tools and conveyor systems. Its roller plunger actuator provides accurate motion detection, and its durable construction ensures steady performance, even in demanding environments. The high mechanical and electrical life span makes this switch a dependable component for continuous, long-term operation.

Rugged Construction Meets High Standards

With a robust metal body, plastic head, and silver alloy contacts, the limit switch combines sturdiness with efficient electrical conductivity. Certified by IEC and CE, and protected with IP65 ingress, the switch is resistant to dust and water, making it ideal for environments where reliability and safety cannot be compromised.

FAQ's of Honeywell Limit Switch HLS-F:

Q: How is the Honeywell HLS-F Limit Switch typically used in industrial automation?

A: The Honeywell HLS-F Limit Switch is commonly integrated into machine tools, conveyor systems, and automated equipment to detect position, motion, or travel limits. When actuated by machinery, it sends signals to control equipment, helping to manage automation sequences and enhance operational safety.

Q: What benefits does the Roller Plunger actuator provide?

A: A Roller Plunger actuator ensures precise and consistent actuation every time, reducing the risk of false triggers. Its robust mechanism allows for smooth operation and effective motion detection, making it suitable for use in repetitive tasks and high-cycle environments.

Q: When should I consider replacing the limit switch?

A: You should replace the switch after it approaches its rated electrical life of 500,000 operations under load or if you notice inconsistent response times, increased contact resistance, or physical wear to the actuator. Regular inspection helps ensure ongoing reliable performance.

Q: Where can this limit switch be installed, and what mounting type does it support?

A: The HLS-F Limit Switch is designed for panel mounting and fits standard-sized enclosures. It can be installed in various industrial environments requiring reliable position feedback, as long as the installation area falls within the specified temperature and protection level requirements.

Q: What is the installation process for this switch regarding wiring?

A: For installation, use the M20 x 1.5 mm wire entry provided. Ensure the switch is mounted securely on a panel using appropriate hardware. Electrical connections should comply with the rated voltage and current, ideally completed by a qualified technician to maintain safety and compliance.

Q: What safety and compliance features does the Honeywell HLS-F offer?

A: This limit switch complies with IEC standards and is CE certified. Its IP65 ingress protection shields against dust and water jets, ensuring reliable operation in industrial settings. The insulation resistance of 100 M (at 500 VDC) also enhances operational safety.
