Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z

Get a Price/Quote

MOQ : 1 Piece

Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z Specification

Mounting Type
Direct Mounted

Phase
Single Phase

Usage & Applications
Hydraulic and Pneumatic Systems, Machinery, Process Control

IP Rating
IP67

Sensor Type
Piezoresistive

Features
Compact Design, Rugged Construction, High Shock and Vibration Resistance

Measuring Range
0-600 bar

Installation Type
Threaded (G1/4 Male)

Frequency
DC

Connectivity Type
Electrical Connector

Display
No Display

Current
4-20 mA

Output
2-40 mA

Protection Level
EMC Protected

Product Type
Pressure Transmitter

Operating Temperature
-40C to +125C

Working Temperature
-40C to +125C

Input
Pressure

Pressure Type
0-600 Bar

Diameter
Approx. 26 mm

Application
Industrial Pressure Measurement

Supply Voltage
10-32 V DC

Accuracy
0.5% FS

Dimension (L*W*H)
Approx. 78 mm x 26 mm x 27 mm

Weight
Approx. 120 g

Overpressure Limit
1200 bar

Burst Pressure
1500 bar

Material (Wetted Parts)
Stainless Steel 316L

Media Compatibility
Suitable for Harsh Fluids

Response Time
<2 ms

Long-Term Stability
0.2% FS/year

Measuring Medium
Liquids and Gases

Electrical Connection
M12x1, 4-pin

Vibration Resistance
25 g (20-2000 Hz)

Shock Resistance
500 g (1 ms)

Compensated Temperature Range
-20C to +85C

Output Signal
4-20 mA (2-wire)

Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Days

Main Domestic Market
All India

About Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z

Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z

Kavlico Pressure Transmitter,Range: 0 to 600 Bar,Output: 4-20mA,Proc.Conn. BSP(M),Elec. Conn.: DIN connector,Hermetically sealed, SS304 Internal /wetted part ,Rugged & durable,SS304 construction ,Compact & Light weight ,Accuracy : 0.2% BFSL, Total Error Band 1%.

Engineered for Reliability

The Kavlico PTE5000-600-1-B-1-Z is built with stainless steel wetted parts, providing durability against corrosive fluids and high-pressure environments. Its advanced EMC protection and IP67 rating ensure stable operation even in the harshest industrial settings, making it suitable for diverse applications across hydraulic, pneumatic, and process industries.

Precision Monitoring and Rapid Response

Boasting an accuracy of 0.5% FS and a response time of less than 2 ms, the transmitter allows for highly precise and real-time pressure monitoring. This ensures operators can trust control feedback even in critical applications where stability and speed are paramount.

FAQ's of Kavlico Pressure Transmitter PTE5000-600-1-B-1-Z:

Q: How do I install the Kavlico PTE5000-600-1-B-1-Z pressure transmitter?

A: Installation is simple due to its threaded G1/4 male connection and direct mounting design. Ensure that the electrical connection is made via the M12x1 (4-pin) connector, and mount the device in the desired industrial location, securing it to withstand vibration and shock.

Q: What types of media can this transmitter measure?

A: The Kavlico PTE5000-600-1-B-1-Z is compatible with a broad range of liquids and gases, including harsh fluids. Its stainless steel 316L wetted parts deliver high resistance to corrosive or aggressive media commonly found in industrial environments.

Q: When is this pressure transmitter most beneficial to use?

A: It excels in demanding applications requiring high accuracy, fast response, and durability-such as hydraulic or pneumatic systems, process control, and machinery monitoring, especially where environmental conditions are severe or media are aggressive.

Q: Where can this pressure transmitter be applied?

A: This model is ideal for use in industrial settings across India and globally, particularly in hydraulic and pneumatic lines, manufacturing machinery, and process automation systems demanding reliable, long-term pressure monitoring.

Q: What are the main benefits of using the Kavlico PTE5000-600-1-B-1-Z?

A: Key benefits include its robust long-term stability, rapid response, high shock and vibration resistance, and compatibility with harsh fluids. Its compact, rugged design enables reliable operation and easy integration in industrial environments.

Q: How does the transmitter ensure measurement accuracy and stability over time?

A: The sensor offers a long-term stability of 0.2% FS per year and an accuracy of 0.5% FS, thanks to its advanced piezoresistive technology and high-grade stainless steel construction, delivering reliable data for critical control and monitoring.

Q: What is the process for connecting the transmitter electrically?

A: Electrically connect the transmitter using an M12x1, 4-pin connector and a 10-32 V DC supply. The current output signal of 4-20 mA (2-wire) allows straightforward integration into existing DC-based industrial monitoring or control systems.
